4 inch dome PTZYou are here:HOME >> PRODUCTS >> H.265 PTZ IP Ca... >> 4 inch dome PTZ
VH-NP-S02

H. 265 4 inch PTZ IR 80M

1/2.5" 5MP AR0521 CMOS Sensor
H.265 Compression Method
10X (f=5.1mm-51mm) Optical Zoom
IR Distance 80M Max
IP66 Outdoor

Enquiry Now

  • We will carefully read your message and reply you as soon as possible.
  • *
  • *
  • * *
  • *
  •
Model No. VH-NP2010-S02 VH-NP5010-S02
Camera
Soc Hi3516CV300 Hi3516D
Sensor 1/3"  CMOS 2MP  Sony323 1/2.5" CMOS 5MP AR0521
Output Pixel 1920x1080/30fps
1920x1080/25fps
2592x1944/15fps
2592x1944/15fps
Lens                                                           10X f=5.1mm~ 51mm
BLC Support
AGC Auto/manual
WB Auto/manual/indoor/outdoor
DNR 2DNR,3DNR
WDR DWDR
S/N Ratio ≥50dB
Dome
Communication Protocol  TCP/IP,HTTP,NTP,IGMP,DHCP,UDP,SMTP,RTP,RTSP,ARP,DDNS,DNS,HTTPS,P2P
Software Control IE, CMS, Management Platform
Mobile View(optional) Support Windows, iPhone platform smartphone
Video compression H.264/H.265/M-JPEG
Audio compression G711,PCM
Rotation Range Pan: 0°~360° , Tilt: 0°~93°
Rotation Speed Pan: 0~45°/s , Tilt:0~30°/s
Auto Flip Horizontal 180°, Vertical 93°
Preset Points 220pcs presetsdwell time 01-60s interval available
A-B scan User programmabel(scan speed 1-64 levels setting available)
Guard Tours 3 groups( Max.16 points, dwell time user selectable)
Operating temperature -40~+60
Operation menu English
Power DC 12V 3A
Consumption  ≤25W
Lightning Protection Transient voltage 6000V
Related validation IP66,CE,FCC,RoHs
IR parameter
Auto Control IR LED PWM
IR distance Up to 80 meters
LEDs 6 PCS Array 42Mil IR LED
Support ambient light detection IR illumination on 1-9 grades selectable
