| Model No. | NP-2020-M02 | NP-2020-M02L | NP-5020-M02 | NP-2036-M02 |
| Camera | ||||
| Soc | Hi3516CV300 | Hi3516D | Hi3516D | Hi3516D |
| Sensor | 1/3" CMOS 2MP Sony323 | 1/2.7" CMOS 2MP Sony290 | 1/2.5" CMOS 5MP AR0521 | 1/3" CMOS 2MP Panasonic34229 |
| Output Pixel | 1920x1080/30fps 1920x1080/25fps |
1920x1080/30fps 1920x1080/25fps |
2592x1944/15fps 2592x1944/15fps |
1920x1080/30fps 1920x1080/25fps |
| Lens | 20X f=4.7mm~94mm | 36X 4.6mm~165mm | ||
| BLC | Support | |||
| AGC | Auto/manual | |||
| WB | Auto/manual/indoor/outdoor | |||
| DNR | 2DNR,3DNR | |||
| WDR | DWDR | WDR≥79dB | DWDR | WDR≥79dB |
| S/N Ratio | ≥50dB | |||
| Dome | ||||
| Communications Protocol | TCP/IP, HTTP, NTP, IGMP, DHCP, UDP, SMTP, RTP, RTSP, ARP, DDNS, DNS, HTTPS, P2P | |||
| Software Control | IE, CMS, Management Platform, P2P | |||
| Mobile View(optional) | Android , iPhone | |||
| Rotation range | Pan:0~360°,Tilt:0~93º | |||
| Rotation speed | Pan:0~380°/s Tilt:0~90°/s | |||
| Auto Flip | Horizontal 180º,Vertical 93º | |||
| Preset Points | 220pcs presets（dwell time 01-60s interval available） | |||
| A-B scan | User programmabel(scan speed 1-64 levels setting available) | |||
| Guard Tours | 8 groups( Max.16 points, dwell time user selectable) | |||
| Pattern Scan | 4 pcs(Max 15 minutes.max.512 commands) | |||
| Time scheduling Function | 6 tasks | |||
| PWR On Action | Memory/Pattern 1/Tour 1/360° scan/A-B scan/Park 1/None | |||
| Park Mode | Pattern 1/Tour 1/360° scan/A-B scan/Park 1/None | |||
| Park Time | 1-60mins setting available | |||
| video compression | H.264/H.265M-JPEG | |||
| audio compression | G711, PCM | |||
| Operating temperature | -40℃~+60℃ | |||
| Operation menu | Mutiple languages:English,Italian,Spanish etc. | |||
| Power | DC12V 4A / (AC24V 3A optional ) | |||
| Consumption | ≤25W | |||
| Lightning Protection | Transient voltage 6000V | |||
| Related validation | IP66,CE,FCC,RoHs | |||
| IR parameters | ||||
| Auto Control IR LED | PWM | |||
| IR distance | 150 meters | |||
| LEDs | 8 Pcs Array 42Mil IR LED | |||
| Support ambient light detection | IR illumination on 1-9 grades selectable | |||
